Sew Eurodrive 1HP Gear Motor 100.80:1 17 RPM Flanged Reducer
Sew Eurodrive 1HP Gear Motor 100.80:1 17 RPM Flanged ReducerSew Eurodrive 1HP Gear Motor 100.80:1 17 RPM Flanged ReducerSew Eurodrive 1HP Gear Motor 100.80:1 17 RPM Flanged ReducerSew Eurodrive 1HP Gear Motor 100.80:1 17 RPM Flanged ReducerSew Eurodrive 1HP Gear Motor 100.80:1 17 RPM Flanged ReducerSew Eurodrive 1HP Gear Motor 100.80:1 17 RPM Flanged ReducerSew Eurodrive 1HP Gear Motor 100.80:1 17 RPM Flanged ReducerSew Eurodrive 1HP Gear Motor 100.80:1 17 RPM Flanged ReducerSew Eurodrive 1HP Gear Motor 100.80:1 17 RPM Flanged ReducerSew Eurodrive 1HP Gear Motor 100.80:1 17 RPM Flanged ReducerSew Eurodrive 1HP Gear Motor 100.80:1 17 RPM Flanged ReducerSew Eurodrive 1HP Gear Motor 100.80:1 17 RPM Flanged ReducerSew Eurodrive 1HP Gear Motor 100.80:1 17 RPM Flanged ReducerSew Eurodrive 1HP Gear Motor 100.80:1 17 RPM Flanged ReducerSew Eurodrive 1HP Gear Motor 100.80:1 17 RPM Flanged Reducer

Sew Eurodrive 1HP Gear Motor 100.80:1 17 RPM Flanged Reducer

Current Price: $427.49
  • Gear Ratio: 100.80:1
  • Output Speed: 17
  • Shaft Diameter: 45MM hollow shaft
  • Output Torque (lbs-in): 2580
  • Shaft Output (Left, Right or Inline): right
  • Motor Brand: sew-eurodrive
  • Motor Catalog Number (Model): DFT80N4
  • Motor HP: 1.00
  • Motor Phase: 3
  • Motor Voltage: 330delta/575Wye
  • Motor Frequency: 60
  • Motor Amps: 2.58/1.48
  • Insulation Class: B
  • This is a new helical inline gear reducer.
  • The vent is damaged from handling and should be replaced.
  • Ratio Is 100.80:1
  • RPM is 17 rpm
  • 45MM hollow shaft  with key
  • Flange on the reducer output side has a 130MM diameter pilot flange and 4 bolt holes on a 165MM pattern.
  • TEFC motor
  • Motor # DFT80N4
  • Motor S.O. # is 850272747.01.01.001
  • Reducer # SAF67DT80N4
  • Reducer S.O. # 850272747.01.01.001
Details
  • Brand: SEW-EURODRIVE
  • Condition: New Other
  • SKU: 213621
  • Consigner: J
  • Warehouse Storage Location: AC-09-03
  • Shipping Weight (lbs, oz): 95,
  • Lister: JW
  • Country of Manufacture: United States
  • Items in Lot: 1
  • Gear Ratio: 100.80:1
  • Output Speed: 17
  • Shaft Diameter: 45MM hollow shaft
  • Output Torque (lbs-in): 2580
  • Shaft Output (Left, Right or Inline): right
  • Motor Brand: sew-eurodrive
  • Motor Catalog Number (Model): DFT80N4
  • Motor HP: 1.00
  • Motor Phase: 3
  • Motor Voltage: 330delta/575Wye
  • Motor Frequency: 60
  • Motor Amps: 2.58/1.48
  • Insulation Class: B
  • This is a new helical inline gear reducer.
  • The vent is damaged from handling and should be replaced.
  • Ratio Is 100.80:1
  • RPM is 17 rpm
  • 45MM hollow shaft  with key
  • Flange on the reducer output side has a 130MM diameter pilot flange and 4 bolt holes on a 165MM pattern.
  • TEFC motor
  • Motor # DFT80N4
  • Motor S.O. # is 850272747.01.01.001
  • Reducer # SAF67DT80N4
  • Reducer S.O. # 850272747.01.01.001
